LUMSDEN SEGMENTED STONE ROTARY GRINDER

For pricing please contact our sales team

Lumsden Segmented Stone Rotary Syrface Grinder

4m Magnetic Bace

Parameter Model 91 ML Model 92 ML Model 93 ML

Magnetic Table Diameter 36" (915 mm) 48" (1220 mm) 60" (1525 mm)

Segmented Wheel Diameter 22" (560 mm) 28" (710 mm) 34" (865 mm)

Max Grinding Height 11" (280 mm) 18" – 22" (450 – 560 mm) 18" (450 mm)

Spindle Motor Power 40 HP (30 kW) 50 HP (37 kW) 60 HP (45 kW)

Spindle Speed ~700 RPM ~550 RPM ~450 RPM

Table Speed 8 & 24 RPM 6 & 18 RPM 5.5 & 16 RPM

Number of Segments 10 or 12 Segments 12 or 14 Segments 14 or 16 Segments

Approx. Weight 7.5 Tons
