Name

Specification

Bending Capacity / Round Tube / Mild Steel (S=40kgf/m ㎡)

65mm x 3mm

Bending Capacity / Round Tube / Non-Ferrous (S=25kgf/m ㎡)

65 × 5 mm

Bending Capacity / Round Tube / Stainless (S=60kgf/m ㎡)

65 ×1.5 mm

Bending Tube – C axis

Hydraulic (Electric as option)

Feeding Tube – Y axis

Electric (Servo Motor)

Rotating Tube – B axis

Electric (Servo Motor)

Pressure die moving

Hydraulic

Mandrel moving

Hydraulic

Lubrication

Auto

Cooling system

Fan or Water cooling

Max. bending radius

150 mm (custom made)

Max. bending angle

190°

Mandrel working length

3600 mm (custom made)

Roundness after bent

＜8% (CLR:1.5D)

Thickness reduce after bent

＜10% (CLR:1.5D)

Bending speed

30-110°/s

Rotating speed

30-210°/s

Feeding speed

250-900mm/s

Bending precision

±0.1°

Feeding precision

±0.1mm

Rotating precision

±0.1°

Max. Pressure

16MP (Adjustable)

Working noise

≤60db

Screen language

English / other

Program storage

Maximum 500 sets
